Material: 7075 Aluminum
Coating: Matte Black Hardcoat
Overall Length: 1.775"
Overall Width: .99"
Torque Specs: 15 in/lbs
(2) 6-32 Button Head Screws - Requires 5/64 Wrench or Driver
(2) 6-32 Flat Head Screws - Requires 5/64 Wrench or Driver
(2) 4-40 x 1/4" Socket Cap Head Screws - Requires 3/32 Wrench or Driver
Red Dot Fitment:
Burris Fast Fire 1, 2, 3, 4
UTG Reflex Micro Dot
Crimson Trace CTS-1200
Crimson Trace CTS-1300
Sightmark Mini Shot
Sightmark Core Shot
*All ADE mounts require 6-32 x 3/8" screws.
Please note: We have found that some red dots commonly found on Amazon such as the UTG and ADE may not hold the same tolerances as the red dots that this mount was initially created to work with. These dots may not fit properly on the posts on the plate. We would recommend either sending the red dot back for an exchange to whichever seller you purchased it from, or open up the holes in the bottom of the red dot to accommodate the pins.
The rear sight plate on your gun needs to be removed to install your red dot on this plate. The plate is mounted to the slide from underneath the slide using the provided 4-40 screws. The red dot is then installed on top of the adapter plate using the provided 6-32 screws.
- Remove the rear sight*
- Install the EGW Sight Mount in the dovetail
- Place the red dot sight on the EGW Sight Mount
(placing a small piece of paper between the red dot sight and the sight mount will make for easier removal and will keep Loctite off of the red dot sight.)
- Apply blue Loctite to the provided mounting screws
- Torque mounting screws to 15in/lbs
Modification of your firearm may nullify the manufacturer's warranty.
This product should be installed and checked by a qualified gunsmith.
No liability is expressed or implied for damage or injury which may result from improper installation or use of this product.Warning: This product may be alloyed with trace amounts of lead and other elements which are known to the State of California to cause reproductive harm and cancer. To prevent exposure, do not alter the product by welding, grinding, etc. For more information, go to www.P65Warnings.ca.gov.
More Information Red Dot Brand ADE RD3-001 / RD3-002 / RD3-006 / RD3-009 / RD3-012 / RD3-013 / RD3-015, Burris FastFire 1, 2, 3, 4, Crimson Trace CTS-1200 / CTS-1300, Docter, Vortex Venom / Viper Firearm Brand Sig Sauer Model M17, M18 Scope Mount Color Black Hardcoat Anodized Type III GTIN 841370111978
