Material: 7075 Aluminum
Coating: Matte Black Hardcoat
Overall Length: 1.811"
Overall Width: .99"
Torque Specs: 15 in/lbs
(2) 6-32 Button Head Screws - Requires 5/64 Wrench or Driver
(2) 6-32 Flat Head Screws - Requires 5/64 Wrench or Driver
(2) 8-40 Torx Screws - Requires T10 Wrench or Driver
Red Dot Fitment:
Burris Fast Fire 1, 2, 3, 4
UTG Reflex Micro Dot
Crimson Trace CTS-1200
Crimson Trace CTS-1300
Sightmark Mini Shot
Sightmark Core Shot
*All ADE mounts require 6-32 x 3/8" screws.
Please note: We have found that some red dots commonly found on Amazon such as the UTG and ADE may not hold the same tolerances as the red dots that this mount was initially created to work with. These dots may not fit properly on the posts on the plate. We would recommend either sending the red dot back for an exchange to whichever seller you purchased it from, or open up the holes in the bottom of the red dot to accommodate the pins.
The EGW red dot sight mount adapter plates for the Savage / Stevens 301 .410 models are meant to be installed in place of the factory rail. Simply remove the rail your gun and replace it with our mount in order to mount your Vortex Viper, Vortex Venom, Burris FastFire, or Docter red dot sight. You can take our mount off and replace your rear sight at any time. Mounting hardware included.
- Remove the factory mount
- Install the EGW Sight Mount on the raised interface
- Secure the plate to the barrel of the gun with the provided screws and torque to 20 in/lbs
- Place the red dot sight on the EGW Mount
(placing a small piece of paper between the red dot sight and the sight mount will make for easier removal and will keep Loctite off of the red dot sight.)
- Apply blue Loctite to the provided red dot mounting screws
- Torque red dot mounting screws to 15in/lbs
2 Button Head Cap Screws - Provided for Vortex Viper and Venom Sights
2 Flat Head Cap Screws - Provided for Burris FastFire and Docter Sights
Modification of your firearm may nullify the manufacturer's warranty.
This product should be installed and checked by a qualified gunsmith.
No liability is expressed or implied for damage or injury which may result from improper installation or use of this product.
Click here to see a video from Vortex on how to install our red dot base on a slide.
Warning: This product may be alloyed with trace amounts of lead and other elements which are known to the State of California to cause reproductive harm and cancer. To prevent exposure, do not alter the product by welding, grinding, etc. For more information, go to www.P65Warnings.ca.gov.
More Information GTIN 841370117611 Scope Mount Color Black Hardcoat Anodized Type III Model 301 (.410 Gauge) Firearm Brand Savage, Stevens Red Dot Brand ADE RD3-001 / RD3-002 / RD3-006 / RD3-009 / RD3-012 / RD3-013 / RD3-015, Burris FastFire 1, 2, 3, 4, Crimson Trace CTS-1200 / CTS-1300, Docter, Vortex Venom / Viper
